Brno Data Centre

The Right Place for Your Data

Brno Data Centre is located in Cejl 20. It has a size of 750 square metres and is preeminently secured.

Steady Power Supply

The data centre is powered by two independent sources of alternating voltage with a 1.000 kVA transformer. Emergency backup is facilitated by an automatic switch-over to Broadcrown and Mistubishi diesel generators.

Hybrid Cooling

In Brno halls, Vertiv air-conditioning units are used, including a direct method of free cooling, double-layer floor, and hot aisle/cold aisle data centre design. All technologies prevent the cold air from potential fusion with the hot air.

Rack Units

The Rittal Rack Unit up to 47 U and/or smaller are available for rent in the data centre. There is also a space for housing tower. UTP power cabels are provided with the technology.

Brno Data Centre Equipment

  • Connection capacity: Nx 10 GbE
  • Direct connection to other DCs: CeColo, MasterDC Prague
  • Electric power backup: a motorgenerator, UPS
  • Capacity of the provided ports: 1, 10, 25, 40, and 100 GbE
  • Air-Conditioning: Vertiv, power backup N+1
  • Access Security: EZS, personnel authorisation, 24/7 support, and physical security
  • Space Monitoring: digital video recorder

Did you know that ...

Inside the data centre there is a room dedicated to customers in which you can use the possibility of connecting to Wi-Fi or wired connectivity? You can temporarily use it to conduct interventions in the servers located in the data centre.

Transport of technologies into Brno Data Centre

The entrance to the Brno data centre is in Cejl 20, 602 00 Brno, not far from the city centre. You can easily reach it both by car and public transport. For drivers, there are reserved parking lots near the building. If you carry electronic complements with you, for transport you can use a loading dock, a forklift and lifts. When working with the technologies onsite, use local KVM consoles. A member of the support or technical team will help you to deploy the technology into a designated place.

Brno Data Centre power specifications

  Branch A Branch B
Transformer 1 000 kVA 1 000 kVA
Diesel generator 700 kVA + 530 kVA 2x 700 kVA
UPS 1x Online modular, scalable 250 kVA, Online UPS, 2x 80 kVA + 2x 40 kVA 2x Online modular, scalable 150 kVA + 250 kVA, Online UPS, 80 kVA + 2x 40 kVA
